LED Squared Garden Pole
The SEGA-M LED Squared Garden Pole is a 2.5-metre ground-mounting squared column LED garden luminaire, powered by 20W COB LEDs, rated IP65. Available in two optical configurations — 27.5° narrow beam and 56.5° spread beam — it delivers 1991–2089 lm at 91–95 lm/W with CRI ≥83.4. The segmented specular reflector with textured glass diffuser delivers controlled, architectural pathway illumination for gardens, residences, pedestrian areas, and landscape parks.
Product Overview
LED Squared Garden Pole The SEGA-M LED Squared Garden Pole is a 2.5-metre ground-mounting squared column LED luminaire, IP65 rated, powered by COB LEDs, designed for landscape lighting in gardens, residences, pedestrian areas, and landscape parks. Its compact squared section profile delivers a clean, modern aesthetic for contemporary landscape projects.
Body & Construction Die-cast and extruded aluminum, electrostatically coated after Phospho-Chromatation. Segmented specular reflector with textured glass diffuser provides controlled beam output. IP65 full outdoor protection. Dimensions: L198×W136×182×B282×H2530 mm.
LED Technology 20W COB LEDs. 27° spread (PSQR1): 2089 lm, 95 lm/W, 27.5° beam, CRI 83.4. 56° spread (PSQR2): 1991 lm, 91 lm/W, 56.5° beam, CRI 83.9. CCT options: 3000K / 4000K / 6000K.
At a Glance
Ordering Information
| Item Code | Item Description | Power (W) | Power Factor | Lumen (lm) | Efficacy (lm/W) | Beam Angle (°) | CRI | CCT (K) | Dimensions (L×N×A×B×L×H) |
|---|---|---|---|---|---|---|---|---|---|
| PSQR1-COB020260-- | LED GARDEN POLE 2.5m SQUARED 27° SPREAD 20W-6000K | 20 | 0.950 | 2089 | 95 | 27.5 | 83.4 | 6000 | 198×136×182×282×298×2530 |
| PSQR1-COB020240-- | LED GARDEN POLE 2.5m SQUARED 27° SPREAD 20W-4000K | 20 | 0.950 | 2089 | 95 | 27.5 | 83.4 | 4000 | 198×136×182×282×298×2530 |
| PSQR1-COB020230-- | LED GARDEN POLE 2.5m SQUARED 27° SPREAD 20W-3000K | 20 | 0.950 | 2089 | 95 | 27.5 | 83.4 | 3000 | 198×136×182×282×298×2530 |
| PSQR2-COB020260-- | LED GARDEN POLE 2.5m SQUARED 56° SPREAD 20W-6000K | 20 | 0.950 | 1991 | 91 | 56.5 | 83.9 | 6000 | 198×136×182×282×298×2530 |
| PSQR2-COB020240-- | LED GARDEN POLE 2.5m SQUARED 56° SPREAD 20W-4000K | 20 | 0.950 | 1991 | 91 | 56.5 | 83.9 | 4000 | 198×136×182×282×298×2530 |
| PSQR2-COB020230-- | LED GARDEN POLE 2.5m SQUARED 56° SPREAD 20W-3000K | 20 | 0.950 | 1991 | 91 | 56.5 | 83.9 | 3000 | 198×136×182×282×298×2530 |
All variants available for export orders — contact us for MOQs, lead times and custom configurations.
Technical Drawings
